Game Development

CezveRender

CezveRender is a real-time 3D renderer built from scratch in Java using OpenGL 3.3 and LWJGL. Created as a learning-focused personal project, it implements core graphics programming concepts...

Status Experimental
Java 17+
Learning curve Steep
Latest release v1.1
CezveRender interface

CezveRender is a real-time 3D renderer built from scratch in Java using OpenGL 3.3 and LWJGL. Created as a learning-focused personal project, it implements core graphics programming concepts including shadow mapping, physically-based lighting models, and scene management entirely in Java. The renderer supports directional, point, and spot lights — each with their own shadow mapping techniques (orthographic, cubemap, and perspective respectively) — along with Phong shading per material. OBJ model loading is handled via Assimp (through LWJGL bindings), and the project includes a live ImGui-powered editor for adding, removing, and transforming scene objects and lights at runtime. Additional features include a procedural mesh generator, skybox rendering, and an adjustable shadow bias debugger. The tech stack is built on LWJGL for low-level OpenGL/GLFW bindings, JOML for vector and matrix math, imgui-java for the in-scene editor UI, and STB for image loading. While experimental and not production-ready, CezveRender is an excellent reference for Java developers interested in learning how to implement a rendering pipeline from scratch on the JVM.

Code Example


                import org.lwjgl.opengl.*;
                import static org.lwjgl.opengl.GL33.*;

                // Basic shader program setup in CezveRender style
                public class ShaderProgram {
                    private final int programId;

                    public ShaderProgram(String vertexSrc, String fragmentSrc) {
                        int vertShader = compileShader(GL_VERTEX_SHADER, vertexSrc);
                        int fragShader = compileShader(GL_FRAGMENT_SHADER, fragmentSrc);

                        programId = glCreateProgram();
                        glAttachShader(programId, vertShader);
                        glAttachShader(programId, fragShader);
                        glLinkProgram(programId);
                        if (glGetProgrami(programId, GL_LINK_STATUS) == GL_FALSE) {
                            throw new RuntimeException("Program link error: " + glGetProgramInfoLog(programId));
                        }

                        glDeleteShader(vertShader);
                        glDeleteShader(fragShader);
                    }

                    private int compileShader(int type, String src) {
                        int shader = glCreateShader(type);
                        glShaderSource(shader, src);
                        glCompileShader(shader);
                        if (glGetShaderi(shader, GL_COMPILE_STATUS) == GL_FALSE) {
                            throw new RuntimeException("Shader compile error: " + glGetShaderInfoLog(shader));
                        }
                        return shader;
                    }

                    public void bind() { glUseProgram(programId); }
                    public void unbind() { glUseProgram(0); }

                    public void setUniform(String name, float value) {
                        glUniform1f(glGetUniformLocation(programId, name), value);
                    }

                    public void cleanup() { glDeleteProgram(programId); }
                }
